Power and connect your network devices with unparalleled flexibility using the MikroTik CRS328-24P-4S+RM Cloud Router Switch. Beyond Innovate offers this robust 1U rackmount switch, ideal for businesses and ISPs needing extensive Power over Ethernet (PoE) capabilities and high-speed fiber connectivity.
The CRS328-24P-4S+RM is a 28-port device, featuring:
24 Gigabit Ethernet ports with versatile PoE output options: Passive PoE, low voltage PoE, and 802.3af/at (PoE/PoE+) with auto-sensing. Each port can deliver up to 30W of power.
4 SFP+ ports for lightning-fast 10 Gbps fiber or Ethernet module connectivity, ensuring high-bandwidth uplinks and backbone connections.
With a dedicated 500W power supply built-in, the switch itself consumes only up to 44W, leaving a guaranteed 450W to power your PoE devices across three independent 8-port groups (150W per group). T
Driven by an 800 MHz CPU and 512 MB of RAM, the CRS328-24P-4S+RM delivers impressive performance with a non-blocking Layer 2 switching capacity of 128 Gbps and a forwarding rate of 95.2 Mpps.
Designed for indoor environments and capable of operating in temperatures from -20°C to +60°C, the MikroTik CRS328-24P-4S+RM is a cost-effective and powerful solution for consolidating your network infrastructure, providing both high-speed data and reliable power delivery from a single device.
Specifications
{
“Specifications – Product code”: “CRS328-24P-4S+RM”,
“Specifications – Architecture”: “ARM 32bit”,
“Specifications – CPU”: “98DX3236”,
“Specifications – CPU core count”: “1”,
“Specifications – CPU nominal frequency”: “800 MHz”,
“Specifications – Switch chip model”: “98DX3236”,
“Specifications – Dimensions”: “443 x 300 x 44 mm”,
“Specifications – RouterOS license”: “5”,
“Specifications – Operating System”: “RouterOS / SwitchOS”,
“Specifications – Size of RAM”: “512 MB”,
“Specifications – Storage size”: “16 MB”,
“Specifications – Storage type”: “FLASH”,
“Specifications – MTBF”: “Approximately 200’000 hours at 25C”,
“Specifications – Tested ambient temperature”: “-20°C to 60°C”,
“Specifications – Suggested price”: “$489.00”,
“Powering – Number of AC inputs”: “1”,
“Powering – AC input range”: “100-240”,
“Powering – Number of PSU slots”: “2”,
“Powering – Max power consumption”: “494 W”,
“Powering – Max power consumption without attachments”: “44 W”,
“Powering – Cooling type”: “2 fans”,
“PoE-out – PoE-out ports”: “Ether1-Ether24”,
“PoE-out – PoE out”: “802.3af/at”,
“PoE-out – Max out per port output (input 18-30 V)”: “1000 mA”,
“PoE-out – Max out per port output (input 30-57 V)”: “450 mA”,
“PoE-out – Max total out (A)”: “20 A”,
“Ethernet – 10/100/1000 Ethernet ports”: “24”,
“Fiber – SFP+ ports”: “4”,
“Peripherals – Serial console port”: “RJ45”,
“Other – CPU temperature monitor”: “Yes”,
“Other – Current Monitor”: “Yes”,
“Other – PCB temperature monitor”: “Yes”,
“Other – Voltage Monitor”: “Yes”,
“Other – Mode button”: “Yes”,
“Certification & Approvals – Certification”: “CE, EAC, ROHS”,
“Certification & Approvals – IP”: “IP00”
}
