Supercharge your home network with the next-generation MikroTik hAP ax², a compact yet incredibly powerful Wi-Fi 6 (802.11ax) router available at Beyond Innovate. Designed to meet the demands of modern households, this device offers a significant upgrade in speed, performance, and security.
The hAP ax² delivers impressive dual-band wireless speeds, with up to 574 Mbps on 2.4 GHz and 1200 Mbps on 5 GHz, totaling AX1800. Its state-of-the-art dual-band, dual-chain radio with 4-4.5 dBi antennas ensures stronger signal coverage and faster data transfer, making it ideal for streaming large media files, online gaming, and supporting numerous connected devices.
At its core, the hAP ax² boasts a modern 864 MHz quad-core ARM CPU and a generous 1 GB of RAM. This robust hardware configuration allows it to handle complex RouterOS features, including advanced firewall rules, IPsec hardware encryption, and intricate network configurations, with ease. With the addition of WPA3 advanced encryption support, your network is more secure than ever before.
Connectivity options are versatile, featuring five Gigabit Ethernet ports, with port 1 supporting both PoE-in (18-28V) and passive PoE-out (up to 600mA). This PoE-out capability is perfect for powering other compatible devices directly from the router, simplifying your setup. The hAP ax² also offers flexible mounting options, allowing it to be positioned vertically, horizontally, or wall-mounted without compromising signal strength.
Choose the MikroTik hAP ax² for a high-performance, feature-packed Wi-Fi 6 router that provides exceptional speed, robust security, and the comprehensive capabilities of MikroTik’s RouterOS, making it the perfect central hub for any modern home network.
Specifications
{
“Specifications – Product code”: “C52iG-5HaxD2HaxD-TC”,
“Specifications – Architecture”: “ARM 64bit”,
“Specifications – CPU”: “IPQ-6010”,
“Specifications – CPU core count”: “4”,
“Specifications – CPU nominal frequency”: “864 MHz”,
“Specifications – Switch chip model”: “IPQ-6010”,
“Specifications – RouterOS license”: “4”,
“Specifications – Operating System”: “RouterOS v7”,
“Specifications – Size of RAM”: “1 GB”,
“Specifications – Storage size”: “128 MB”,
“Specifications – Storage type”: “NAND”,
“Specifications – MTBF”: “Approximately 100’000 hours at 25C”,
“Specifications – Tested ambient temperature”: “-40°C to 50°C”,
“Specifications – IPsec hardware acceleration”: “Yes”,
“Specifications – Suggested price”: “$99.00”,
“Wireless capabilities – Wireless 2.4 GHz Max data rate”: “574 Mbit/s”,
“Wireless capabilities – Wireless 2.4 GHz number of chains”: “2”,
“Wireless capabilities – Wireless 2.4 GHz standards”: “802.11b/g/n/ax”,
“Wireless capabilities – Antenna gain dBi for 2.4 GHz”: “4”,
“Wireless capabilities – Wireless 2.4 GHz chip model”: “QCN-5022”,
“Wireless capabilities – Wireless 2.4 GHz generation”: “Wi-Fi 6”,
“Wireless capabilities – Wireless 5 GHz Max data rate”: “1200 Mbit/s”,
“Wireless capabilities – Wireless 5 GHz number of chains”: “2”,
“Wireless capabilities – Wireless 5 GHz standards”: “802.11a/n/ac/ax”,
“Wireless capabilities – Antenna gain dBi for 5 GHz”: “4.5”,
“Wireless capabilities – Wireless 5 GHz chip model”: “QCN-5052”,
“Wireless capabilities – Wireless 5 GHz generation”: “Wi-Fi 6”,
“Wireless capabilities – WiFi speed”: “AX1800”,
“Ethernet – 10/100/1000 Ethernet ports”: “5”,
“Ethernet – Number of 1G Ethernet ports with PoE-out”: “1”,
“Powering – Number of DC inputs”: “2 (PoE-IN, DC jack)”,
“Powering – DC jack input Voltage”: “12-28 V”,
“Powering – Max power consumption”: “27 W”,
“Powering – Max power consumption without attachments”: “12 W”,
“Powering – Cooling type”: “Passive”,
“Powering – PoE in”: “Passive PoE”,
“Powering – PoE in input Voltage”: “18-28 V”,
“PoE-out – PoE-out ports”: “Ether 1”,
“PoE-out – PoE out”: “Passive PoE”,
“PoE-out – Max out per port output (input 18-30 V)”: “600 mA”,
“PoE-out – Total output power”: “16.8W”,
“Certification & Approvals – Certification”: “CE, FCC, IC, EAC, ROHS”,
“Certification & Approvals – IP”: “20”,
“Other – CPU temperature monitor”: “Yes”,
“Other – Mode button”: “Yes”,
“Wireless specifications – 1MBit/s”: “27”,
“Wireless specifications – 11MBit/s”: “27”,
“Wireless specifications – 6MBit/s”: “26”,
“Wireless specifications – 54MBit/s”: “23”,
“Wireless specifications – MCS0”: “26”,
“Wireless specifications – MCS7”: “22”,
“Wireless specifications – MCS9”: “20”,
“Wireless specifications – MCS11”: “18”
}
